MRAR Scientific & Laboratory Division

Very gentle mixing with new Fishtail stirrer

Adapter for very sensitive cells

Culture volumes from 35 ml to 6000 ml

MINIFOR is very compact

Fully automatic gas flow

Automatic pH and pO2 control

Self-cleaning gas microsparger

All these features result in a dramatic improvement of the cell culture, precise control of preset parameters and their easy documentation.

The Minifor was developed as a result of the need to construct a small laboratory fermentor for volumes from 0.035 to 4.5l.

Based on long personal practical experience in fermentation we wanted to create a laboratory fermentor, which was easy to use and with the capacity to measure and control all the important parameters of the biological culture.

The fermentor had to take up minimum space on the bench but with a good access to all parts.

Several laboratory fermentors should, when placed side by side be suitable for the optimisation of the parameters of growth of culture or optimisation of biotransformations etc.

Each fermentor should be able to work independently or be connected to a PC for advanced regulation and extensive data treatment.

Collects fractions in any racks of your choice

Collects unlimited number of fractions

The electronics and moving parts are placed above the tubes
– No damage due to spilling

Can be placed in a cold bath or any other thermo-stabilized container

Unlimited number of programmes

Extremely easy programming of rack and tube position by means of a white pen

Fractionation according to time (0.1–999.9 min and 1–9999 min) or volume (0.05–500 ml or 0.1 to 30 l)

Good quality for a fair price

Solvent resistant construction

Tubes easily accessible from all sides

Pause (from 0 to 999.9 min and 1 to 9999 min) or rinsing can be programmed between fractions

Up to 18 fractions simultaneously; multi-channel operation (optional)

Collection in lines or zigzag (meander like)

RS-232 interface (optional)

Practical, precise and reliable pumps - the most compact in their class.

Flow rates from 0.01 to 10’000 ml/hour

Large digital speed setting range from 0 to 999

New motor technology

Extensive remote controls

Greatly extended tubing life with decreased pulsation

Flow rate programming (up to 99 steps) and
automatic switch-on and -off without using any timer

Very economic in use; virtually noiseless operation

Most compact pump of this type on the market

Access to reaction kinetics by using the Pump-Flow INTEGRATOR

Low voltage plug-in power supply for maximum safety

RS-485 interface (optional)

Control software PNet (optional)

New syringe fixing system “VIT-FIT” allows almost any syringe to be used without adapter (from micro-syringes to large volume syringes of 150 ml and more)

The syringe is tightly held in both directions – infusion and filling

Highest mechanical stability allows for high pumping forces and precise flow rates without pulsation

Programmable (99 steps for infusion and filling)

Very easy handling of the syringes

Swiss quality motor and ball screws

RS-485 interface (optional)

Control software PNet (optional)

For automatic or continuous addition of solids, powders, crystalline substances, nano-materials and nano powders without a spoon

Dosing speed range from 0 to 999

Reproducible dosing flow rates (e.g.
50 mg/min to 50 g/min for NaCl)

Easy assembly and cleaning

Necessary to comply with GLP requirements and safety standards

Hermetic construction allows operation in controlled atmospheres (Ar, N2,…)

Safe handling of dangerous and toxic substances

RS-485 interface (optional)

Control software PNet (optional)

Allows the control of pH of cell cultures by controlled addition of gaseous CO2, N2
or any other gas with a suitable controller

High-quality laminar mass flow sensor with minimal pressure drop

Can be used independently - all functions accessible from the front panel

Flow rates from 0 – 500 ml/min or 0 – 5 l/min

Flow rate regulated by a proprietary proportional
needle valve controlled by a microprocessor

Linearity error less than ± 3 % reading (which is
much better than precision expressed as percent of full scale used by some producers)

Repeatability better than ± 0.5% reading

Programmable flow rates

Flow volume can be recorded with INTEGRATOR

RS-485 interface (optional)

Control software PNet (optional)

Control of pH during chemical reactions where the pH is controlled by addition of acid or base
(hydrolysis of esters, amides, anhydrides etc.)

Measurements of enzyme activities of numerous
enzymes (esterases, acylases, lipases, proteases
and others using a pH-stat)

Control and quantification of metabolical activity of cells during fermentations and cell-cultures (by
control of pH, rH, pO2, pCO2, conductivity or other required parameter)

Recording of foam formation (automatic addition of antifoam agent)

Recording of addition of reactives during exothermic reactions with addition of reactive controlled by a thermostat

Recording of consumption of reactives during titration making of gradient for gels, chromatography etc.
